Көлемді сұйық бөтелкелерді толтыру машинасы

Үйге / Құю машиналары / Бөтелке толтыру машинасы / Көлемді сұйық бөтелкелерді толтыру машинасы

Көлемді сұйық бөтелкелерді толтыру машинасы

Жұмыс принципі


1. Manually put the bottles & the caps separately into the Tilted Hopper & Cap vibrator. The Bottle will be arranged by the Tilted Hopperwith bottle bottom towards rear & bottle mouth towards front, lies on the Feeding Conveyer Belt to be deliveredto the Bottle Unscrambler.

2. Bottle neck upward, bottle bottom backward, laid bottle come into bottle unscrambler; after unscrambing, bottles will stand up and be transfered into filling station on the conveyor.

3. Eye detecting station: it detects if there are Bottles to be filled.

4. No Bottles no filling.

5. Filling station: when the Bottles arrive under filling station, filling nozzles will dive into the Bottle for filling the product.

6. Cap loading station: caps will be sorted under vibrator and drop on the mouth of Bottle one by one.

7. Cap tightening station: to tighten the caps for Bottles under specialized device.

8. Discharging station: finished products will be pushed out by poking fork and delivered on outfeed conveyor.

Басқару панелі


Машинаны іске қосу / тоқтату және вибратордың, конвейердің және жұмыс үстелінің жылдамдығын реттеу үшін машинада басқару панелі орнатылған.

Жылдам мәліметтер


Түрі: құю машинасы, құю машинасы
Шарты: Жаңа
Қолдану: химиялық, тауарлық, тамақ, машина және жабдық, медициналық, тамақ, медициналық, химиялық, фармация
Қаптама түрі: бөшке, бөтелке, банка, стенд дорбасы
Қаптама материалы: әйнек, металл, пластик
Автоматты баға: Автоматты
Жетек түрі: Электр
Кернеуі: 110В / 60Гц бір фазалы
Қуаты: 1,5 кВт
Шығу орны: Шанхай, Қытай (материк)
Бренд атауы: NPACK
Өлшемі (L * W * H): 2000 * 750 * 1450 мм
Салмағы: 680кг
Сертификаттау: CE
Сатудан кейінгі қызмет: Инженерлер шетелдегі техникаларға қол жетімді
атауы: кілегей толтыру машинасы
қолдану: шприц
қуаты: 0,22 м3 / мин
Қапталу өнімділігі: ≥99%
жылдамдығы: сағатына 3000 дана
Толтыру көлемі: 15мл


An automatic volumetric liquid bottle filling machine is a piece of equipment that is used to fill bottles with liquid accurately and efficiently. This machine works by measuring the volume of the liquid being dispensed and filling the bottle up to the predetermined level. This is done through the use of sensors and other control mechanisms that ensure that the liquid is dispensed at a consistent rate and with a high level of accuracy.

One of the main advantages of using an automatic volumetric liquid bottle filling machine is the speed and efficiency that it offers. With this machine, it is possible to fill large numbers of bottles quickly and accurately, which can help to increase productivity and reduce the amount of time and labor required for the process.

Another advantage of this type of machine is its versatility. It can be used to fill bottles of different sizes and shapes, as well as different types of liquids, such as water, juice, oil, and other liquids. This makes it ideal for use in a wide range of industries, including the food and beverage industry, the pharmaceutical industry, and the cosmetic industry.

Overall, an automatic volumetric liquid bottle filling machine is a highly effective and efficient piece of equipment that can help businesses to increase their productivity and reduce costs. Whether you are filling bottles of water or filling bottles of medicine, this machine is an essential tool for any modern manufacturing process.
